Junior Student Monocular Microscope BM-3
Junior Student Monocular Microscope BM-3
Low stock: 10 left
Couldn't load pickup availability
Compound Student Microscope BM-3 is designed for school and college biology laboratories, providing reliable optical performance for routine specimen observation. The microscope features a triple revolving nosepiece for quick objective changes, wide-field eyepieces for comfortable viewing, and coarse and fine focusing for accurate image adjustment. It is equipped with a fixed Abbe condenser with N.A. 1.20 and iris diaphragm for proper illumination control. The microscope is built to ISI standards, ensuring consistent quality for educational use.
Key Features
ISI-marked microscope complying with IS:3686:1966 standards
Triple revolving nosepiece for quick objective switching
Wide-field eyepieces 10x and 15x for comfortable viewing
Objectives 10x and 45x for routine biological observation
Fixed Abbe condenser N.A. 1.20 with iris diaphragm
Coarse and fine focusing system for precise adjustment
Supplied in thermocole box for safe storage
Suitable for school and college biology laboratories
Differentiator vs BM-2: Triple nosepiece and ISI-certified build
Differentiator vs BM-3A / Ultra: Standard model offering best value
Product Specifications
| Parameter | Specification |
|---|---|
| Microscope Type | Compound Student Microscope |
| Viewing Head | Monocular |
| Nosepiece | Triple revolving |
| Eyepieces | 10x & 15x |
| Objectives | 10x, 45x |
| Condenser | Fixed Abbe Condenser N.A. 1.20 |
| Diaphragm | Iris diaphragm |
| Focusing System | Coarse and fine focusing |
| ISI Mark | IS:3686:1966 |
| Packaging | Thermocole box |
| Application | School and college biology labs |
| Country of Origin | India |
