Student Monocular Single Nosepiece Microscope BM-1
Student Monocular Single Nosepiece Microscope BM-1
Low stock: 10 left
Couldn't load pickup availability
Student Monocular Microscope BM-1 is designed for introductory microscopy in school laboratories and basic science education. The microscope features a simple single nosepiece design for ease of use by beginners, along with coarse and fine focusing controls for clear image adjustment. It includes a fixed condenser with iris diaphragm for controlled illumination and a compact, lightweight structure for easy handling by students. This makes it ideal for introducing fundamental microscopy concepts in educational environments.
Key Features
Single nosepiece design for easy use by beginners
Coarse and fine focusing system for clear image adjustment
Fixed condenser N.A. 1.20 with iris diaphragm
Eyepiece 10x with 10x objective for basic observation
Compact and lightweight design suitable for students
ISI-mark compliant optical system for reliable performance
Ideal for introductory school science laboratories
Differentiator vs BM-2: Single nosepiece design makes it simpler and more affordable
Product Specifications
| Parameter | Specification |
|---|---|
| Microscope Type | Dissecting Microscope |
| Viewing Head | Monocular |
| Magnification Range | 10X – 20X |
| Eyepieces | Wide Field High Eye-Point 10X and 20X |
| Stage Size | Approx. 85 × 75 mm |
| Stage Type | Glass stage with spring specimen clips |
| Stage Plates | Interchangeable white and black contrast plates |
| Focusing System | Rack and pinion coarse focusing |
| Focus Travel | Approx. 15 mm |
| Working Distance | Suitable for specimen handling and dissection |
| Illumination | Sub-stage plano-concave mirror |
| Optical Arm | Jointed arm allowing scanning across stage |
| Body Construction | Metal body with precision optical components |
| Base | Heavy round metal base |
| Applications | Zoology laboratories, botany studies, entomology observation, specimen dissection, educational laboratories |
