Medical Microscope BM-5

Medical Laboratory Microscope BM-5 is designed for advanced observation in medical colleges, pathology laboratories, and research environments. The microscope offers high-precision optics with a wide-field eyepiece and a full objective range including oil immersion for detailed specimen analysis. It features a quadruple revolving nosepiece, a detachable mechanical stage for accurate slide scanning, and a high-performance Abbe condenser with N.A. 1.25 for enhanced illumination and contrast. The halogen illumination system provides bright and stable lighting, making it suitable for routine and advanced laboratory applications.

Key Features

ISI-marked senior laboratory microscope for reliable performance
Abbe condenser N.A. 1.25 with rack-and-pinion movement
Graduated fine motion with precision up to 0.002 mm
Detachable mechanical stage for precise slide scanning
100x oil immersion objective for detailed pathological studies
Wide-field eyepiece options for comfortable viewing
6V/20W halogen illumination for bright and stable lighting
Suitable for medical colleges, pathology labs and research work
Differentiator vs BM-4: Higher N.A. condenser and mechanical stage for advanced observation
Differentiator vs BM-5 Ultra: Standard model without LED and battery backup features

Technical Specifications
